Description
Flowatch FL-03 Portable Flow Meter adalah alat ukur aliran air portabel yang dirancang untuk memberikan pengukuran cepat, akurat, dan mudah digunakan. Dengan desain ringkas serta bobot ringan, alat ini sangat praktis dibawa ke lapangan, cocok untuk teknisi, peneliti, maupun instansi yang membutuhkan data aliran cairan secara real-time.
Alat ini dilengkapi dengan layar digital yang jelas, sensor berpresisi tinggi, serta fitur pencatatan data yang memudahkan analisis. Aplikasinya luas, mulai dari penelitian lingkungan, sistem irigasi, distribusi air, hingga kebutuhan industri. Pengguna dapat melakukan pemantauan aliran air tanpa instalasi rumit karena desain portabel dan user-friendly.
SPESIFIKASI Flowatch Fl-03
Speed measurement – Standard size propeller
| Units of measurement | km/h, m/s, cm/s, mph, fps, knots and Beaufort |
| Resolution | 0.1 for all units (except cm/s: 3 cm/s) |
| Maximum speed | 150 km/h (except cm/s: 999 cm/s) |
| Diameter (gas) | Ø 20mm |
| Through hole | Ø 33mm |
| Range of measurement | from 1 to 30 m/s |
| Minimum sensitivity | < 3 km/h – < 1 m/s |
| Precision | ± 2% FS |
| ‘Off-axis’ error | ± 30° / ± 3% FS |
| Operating temperature | -50°C to +100°C |
Speed measurement – Small size propeller
| Units of measurement | km/h, m/s, cm/s, mph, fps, knots et Beaufort |
| Resolution | 0.1 for all units (except cm/s: 3 cm/s) |
| Maximum speed | 150 km/h (except cm/s: 999 cm/s) |
| Diameter (gas) | Ø 12mm |
| Through hole | Ø 18mm |
| Range of measurement | from 1 to 30 m/s |
| Minimum sensitivity | < 3 km/h – < 1 m/s |
| Precision | ± 2% FS |
| ‘Off-axis’ error | ± 10° / ± 3% FS |
| Operating temperature | -50°C to +100°C |
Speed measurement – Water propeller
| Units of measurement | km/h, m/s, cm/s, mph, fps, knots and Beaufort |
| Resolution | 0.1 for all units (except cm/s: 3 cm/s) |
| Maximum speed | 150 km/h (except cm/s: 999 cm/s) |
| Diameter (gas) | Ø 60mm |
| Range of measurement | from 0.1 to 10 m/s |
| Minimum sensitivity | < 0.3 km/h – < 0.1 m/s |
| Precision | ± 2% FS |
| ‘Off-axis’ error | ± 20° / ± 3% FS |
Temperature measurement
| Units of measurement | °C, °F, perceived °C and perceived °F |
| Thermometer accuracy | ± 0.2°C |
| Resolution | ± 0.1°C |
| Functions | measuring air, perceived, minimum, average and maximum temperature |
